Product Description
**Milwaukee parts change not only by model# but also by serial number. To look up your tools parts break down on Milwaukees website please click here:
Milwaukee XP50F 20mm Field Assembly
Model Number: 18-01-3020
The Milwaukee 18-01-3020 is a genuine OEM XP50F 20mm Field Assembly for use in compatible Milwaukee corded tools. The field assembly — also called the stator — is the stationary electromagnetic winding assembly that surrounds the rotating armature in a universal motor, generating the magnetic field that drives armature rotation and produces motor torque. The field is wound with copper wire to precise specifications that determine the motor's speed, torque, and current characteristics. A field assembly that has failed due to insulation breakdown, burnt windings, or open circuits results in loss of power, excessive current draw, overheating, or complete motor failure — requiring replacement to restore full motor performance and safe tool operation.
Using a genuine Milwaukee OEM field assembly ensures the correct wire gauge, turn count, winding configuration, and insulation rating for the motor it serves. Non-OEM field assemblies may not match the original motor specifications, leading to reduced performance or premature motor failure. Always verify your catalog number and serial number on Milwaukee's website before ordering to confirm this is the correct field assembly for your specific unit.
Features
- Genuine Milwaukee OEM XP50F 20mm field assembly for compatible Milwaukee corded tools
- Stationary winding assembly generates the electromagnetic field driving armature rotation
- Wound to precise specifications controlling motor speed, torque, and current draw
- Restores full motor performance when the original field fails due to burnt or open windings
- Verify catalog number and serial number on Milwaukee's website before ordering
Specifications
- Type: Field Assembly (Stator)
- Designation: XP50F
- Frame Size: 20mm
- Material: Copper Windings on Laminated Steel Core
- Application: Universal Motor Electromagnetic Field Generation
- Compatible Tool Type: Milwaukee Corded Power Tools
Includes
- (1) Milwaukee 18-01-3020 XP50F 20mm Field Assembly
